Instruments

PRODUCTS DETAIL

Qsep1-Lite

- The entry-level capillary electrophoresis Bio-Fragment Analyzer for DNA and RNA.
- The “one-cartridge-one-method” system is simple and straightforward for anyone to use.
- Advantages over traditional gel electrophoresis include higher resolution and sensitivity, providing highly precise evaluation of samples.
- The provided quantitative method delivers fragment size and concentration information in one run.
PRODUCTS DETAIL

Qsep1

- The smallest/portable-sized capillary electrophoresis Bio-Fragment Analyzer for DNA, RNA and protein.
- Qsep1 is ideal for small laboratories with low throughput (1~8 samples) needs.
- The system supports Wi-Fi and cable connections, breaking the barriers of space.
- 10+ types of cartridges can be easily exchanged between various applications.
- The provided quantitative method delivers fragment size and concentration information in one run.
PRODUCTS DETAIL

Qsep1-Plus

- The smallest/portable-sized capillary electrophoresis Bio-Fragment Analyzer for DNA, RNA and protein.
- Qsep1-Plus is ideal for small laboratories with low throughput (1~16 samples) needs.
- The system supports Wi-Fi and cable connections, breaking the barriers of space.
- 10+ types of cartridges can be easily exchanged between various applications.
- The provided quantitative method delivers fragment size and concentration information in one run.


Model Name	Qsep1-Lite	Qsep1	Qsep1-Plus	Qsep100	Qsep 100 2.0	Qsep100 advance	Qsep100 2.0 advance	Qsep400
Separation Voltage	1~8kV	1~8kV	1~8kV	1~15kV	1~15kV	1~15kV	1~15kV	1~15kV
Connection	Ethernet Cable	Wifi/ Ethernet Cable	Wifi/ Ethernet Cable	USB	USB	USB	USB	USB
Power Source	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V	AC 100-240V
Maximum Power	80W	80W	80W	60W	120W	60W	120W	120W
System Weight	5.5kgs	5.5kgs	5.5kgs	15kgs	16.5kgs	15kgs	16.5kgs	26kgs
Dimension	24x 21x 30cm	24x 21x 30cm	24x 21x 30cm	38x 30x 40cm	41x 30x 43cm	38x 30x 40cm	41x 30x 43cm	54x 40x 36cm
System Type	1 Channel Portable System	1 Channel Portable System	1 Channel Portable System	1 Channel Standard System	1 Channel Standard System	1 Channel Standard System	1 Channel Standard System	4 Channel System
Automated Sampling	1~8 samples	1~8 samples	1~16 samples	1~96 samples	1~96 samples	1~96 samples	1~96 sample	4~96 samples
Minimum Sample Volume	2μl sample (0.1mL Tube: C104252)	2μl (Micro-Vial) 10μl (0.1 mL Tube) 20μl (0.2 mL Tube)	2μl (Micro-Vial) 10μl (0.1 mL Tube) 20μl (0.2 mL Tube)	2μl (Micro-Vial) 10μl (0.1 mL Tube) 20μl (0.2 mL Tube)	2μl (Micro-Vial, C104250) 10μl (0.1 mL Tube) 10μl (0.2 mL Tube)	2μl (Micro-Vial) 10μl (0.1 mL Tube) 20μl (0.2 mL Tube)	2μl (Micro-Vial, C104250) 10μl (0.1 mL Tube) 10μl (0.2 mL Tube)	2μl (Micro-Vial) 10μl (0.1 mL Tube) 20μl (0.2 mL Tube)
