Qsep Ultra
Qsep Ultra
Qsep Ultra is a multifunctional POCT solution that integrates PCR and capillary electrophoresis systems, enabling a seamless “sample in, result out” etection process. As an open platform, it is compatible with most PCR-based reagent kits, allowing users to access a wide range of test items at any time. In addition to kit detection solution, the system can be a standard PCR machine or a fragment analyzer. It can analyze various DNA and RNA sample fragments, including sizing, integrity and profiling.
Inquiry
Linear operation procedure combine with graphic illustration.
Easily can be operated by non-medical laboratory professionals.
-Assays: PCR+CE: Sample In Result Out Best partner for various detection kits
-PCR: 8 sample capacity Excellent uniformity and fast ramp rate
-CE: Multiple Applications PCR product/ NGS QC (total RNA integrity/ gDNA/ cfDNA/ FFPE DNA and RNA/ library QC…).
Open Platform:
Open for PCR based assays which able to be analyzed by capillary electrophoresis.Our professional team will support you to apply the assay on the Qsep Ultra platform.
|
Specification |
Highlights |
||
|
Detection |
Fluorescence |
Automated Sampling |
1~8 samples |
|
Light Source |
LED |
Rapid Analysis |
2~7 mins/ sample (below 1 kb) |
|
Separated Voltage |
1~8 kV |
Resolution |
1~4 bp (below 500 bp) |
|
Connection |
USB |
Sensitivity |
5 pg/ µL *1pg/ µL (If diluted in ddH2O) |
|
Power Source |
AC 100~240 V |
Minimum Sample Volume |
10 μL* |
|
Power |
160 W |
Sample Consumption |
≤ 1 pL |
|
System Weight |
14 kg |
Software: Q-Analyzer |
Relative qualitative and quantitative analysis Electrophoresis |
|
Dimension |
39.5*30*37 cm |
|
* Only for CE Mode |
For the details of installation and operation of Qsep100, please refer to the "Support & Download" (Click).
